Brief: Discover the Advanced Impact Strength Tester for Top-Loading Washing Machines, designed to evaluate the mechanical strength of appliance lids. This tester complies with IEC 60335-2-7:2008 and IEC 60335-2-4 standards, ensuring reliable and accurate results for your quality control needs.
Related Product Features:
Tests impact resistance of top-loading washing machine lids according to IEC standards.
Uses a 20 kg impact hammer with a rubber hemisphere for precise testing.
Electromagnetic release and electric lifting for efficient operation.
Drop height of 100 mm delivers an equivalent impact energy of 20 J.
Performs three test cycles to ensure thorough evaluation.
Compatible with sample sizes up to 800 × 1000 × (500-1000) mm.
Single-station design for focused and consistent testing.
Powered by AC220V ±10% / 50-60 Hz for global usability.
Câu hỏi thường gặp:
What standards does the Advanced Impact Strength Tester comply with?
The tester is designed and manufactured according to IEC 60335-2-7:2008 clause 21.101.1 and IEC 60335-2-4 clause 21.101.
How does the impact test work?
The device uses an electromagnet to hold a 20 kg impact hammer, which is released from a height of 100 mm to impact the lid with an energy of 20 J. The test is repeated three times.
What is the hardness of the rubber hemisphere used in the tester?
The rubber hemisphere has a diameter of 70 mm and a hardness of 40-50 IRHD.
