IEC 62196-1 Rewireable Plugs and Vehicle Connector Mechanical Strength Testing Equipment

September 05, 2025
This testing device is required by IEC 62196-1:2022 clause 26.3, fig 19.
It is used to test the mechanical strength of rewirable plugs and vehicle connector which is equipped with flexible cable.
Test principle is that the free end of the cable and an additional rope or other flexible means, etc., attached to the flexible cable, both having a total length of 2,25 m, is fixed to a wall at a height of 1 m above the floor.
The sample is held so that the cable is horizontal and then it is allowed to fall on to a concrete floor. This is done eight times; the cable being rotated through 45° at its fixing each time.
